flutter_for_openharmony手语学习app实战+首页实现
本文介绍了使用Flutter for OpenHarmony开发手语学习App首页的过程。首页采用SingleChildScrollView实现可滑动布局,包含用户欢迎卡片、学习进度、快捷入口和推荐课程等模块。欢迎卡片采用渐变背景设计,显示用户信息和学习天数;学习进度模块使用percent_indicator库展示进度条;快捷入口提供常用功能跳转。整体界面通过flutter_screenutil实

最近在做一个手语学习类的App,用Flutter for OpenHarmony来开发。首页作为用户打开App后看到的第一个界面,承载了很多功能入口和信息展示,今天就来聊聊这个首页是怎么搭建的。
整体思路
首页要展示的内容挺多:用户信息卡片、今日学习进度、快捷操作入口、推荐课程、学习分类等。考虑到内容较多,整个页面采用SingleChildScrollView包裹,让用户可以滑动查看。
先看下页面的基本骨架:
class HomeScreen extends StatelessWidget {
const HomeScreen({super.key});
Widget build(BuildContext context) {
return Scaffold(
appBar: AppBar(
title: const Text('手语学习'),
actions: [
IconButton(
icon: const Icon(Icons.search),
onPressed: () => Navigator.push(
context,
MaterialPageRoute(builder: (_) => const SearchScreen()),
),
),
],
),
这里用了Scaffold作为页面的基础框架,AppBar设置了标题和右侧的搜索按钮。点击搜索图标会通过Navigator.push跳转到搜索页面。
body: SingleChildScrollView(
padding: EdgeInsets.all(16.w),
child: Column(
crossAxisAlignment: CrossAxisAlignment.start,
children: [
_buildWelcomeCard(context),
SizedBox(height: 16.h),
_buildDailyProgress(context),
SizedBox(height: 16.h),
_buildQuickActions(context),
SizedBox(height: 16.h),
_buildRecommendSection(context),
],
),
),
);
}
}
body部分用SingleChildScrollView包裹一个Column,各个模块依次排列。这里用了flutter_screenutil做屏幕适配,.w和.h分别是宽度和高度的适配单位。
用户欢迎卡片
首页顶部是一个渐变背景的欢迎卡片,展示用户头像、昵称和连续学习天数:
Widget _buildWelcomeCard(BuildContext context) {
final userProvider = Provider.of<UserProvider>(context);
return Container(
padding: EdgeInsets.all(20.w),
decoration: BoxDecoration(
gradient: const LinearGradient(
colors: [Color(0xFF00897B), Color(0xFF4DB6AC)],
begin: Alignment.topLeft,
end: Alignment.bottomRight,
),
borderRadius: BorderRadius.circular(16.r),
),
渐变背景用LinearGradient实现,从左上到右下,颜色从深青色过渡到浅青色。BoxDecoration可以设置容器的装饰效果,包括背景色、渐变、圆角等。
child: Row(
children: [
CircleAvatar(
radius: 30.r,
backgroundColor: Colors.white,
child: Icon(
Icons.person,
size: 35.sp,
color: const Color(0xFF00897B)
),
),
SizedBox(width: 16.w),
Expanded(
child: Column(
crossAxisAlignment: CrossAxisAlignment.start,
children: [
Text(
'你好,${userProvider.userName}',
style: TextStyle(
fontSize: 20.sp,
fontWeight: FontWeight.bold,
color: Colors.white
),
),
Text(
'已连续学习 ${userProvider.consecutiveDays} 天',
style: TextStyle(fontSize: 14.sp, color: Colors.white70),
),
],
),
),
],
),
);
}
头像部分用了CircleAvatar组件,设置白色背景配合主题色图标,和渐变背景形成对比。userProvider是通过Provider获取的状态管理对象,数据变化时界面会自动刷新。
今日学习进度
学习类App少不了进度展示,这里用了percent_indicator库的线性进度条:
Widget _buildDailyProgress(BuildContext context) {
final appProvider = Provider.of<AppProvider>(context);
final progress = appProvider.todayLearned / appProvider.dailyGoal;
return GestureDetector(
onTap: () => Navigator.push(
context,
MaterialPageRoute(builder: (_) => const DailyTaskScreen()),
),
首先从appProvider获取今日已学数量和每日目标,计算出进度百分比。整个卡片包了一层GestureDetector,点击可以跳转到每日任务详情页。
child: Card(
child: Padding(
padding: EdgeInsets.all(16.w),
child: Column(
crossAxisAlignment: CrossAxisAlignment.start,
children: [
Row(
mainAxisAlignment: MainAxisAlignment.spaceBetween,
children: [
Text(
'今日学习进度',
style: TextStyle(fontSize: 16.sp, fontWeight: FontWeight.bold)
),
Text(
'${appProvider.todayLearned}/${appProvider.dailyGoal}',
style: TextStyle(fontSize: 14.sp, color: Colors.grey)
),
],
),
SizedBox(height: 12.h),
LinearPercentIndicator(
lineHeight: 12.h,
percent: progress.clamp(0.0, 1.0),
backgroundColor: Colors.grey[200],
progressColor: const Color(0xFF00897B),
barRadius: Radius.circular(6.r),
animation: true,
),
],
),
),
),
);
}
progress.clamp(0.0, 1.0)确保进度值在0到1之间,防止数据异常时进度条显示出问题。LinearPercentIndicator的animation: true开启了动画效果,体验更好。
快捷操作入口
首页中间放了四个快捷入口,方便用户快速进入常用功能:
Widget _buildQuickActions(BuildContext context) {
final actions = [
{'icon': Icons.play_circle_filled, 'label': '继续学习', 'color': Colors.blue},
{'icon': Icons.quiz, 'label': '每日测验', 'color': Colors.orange},
{'icon': Icons.bookmark, 'label': '我的收藏', 'color': Colors.pink},
{'icon': Icons.history, 'label': '学习记录', 'color': Colors.purple},
];
把数据放在List里,包含图标、文字和颜色三个属性。这样写的好处是后续要加减入口只需要改数组就行,维护起来很方便。
return Row(
mainAxisAlignment: MainAxisAlignment.spaceAround,
children: actions.map((action) {
return GestureDetector(
onTap: () {},
child: Column(
children: [
Container(
padding: EdgeInsets.all(12.w),
decoration: BoxDecoration(
color: (action['color'] as Color).withOpacity(0.1),
borderRadius: BorderRadius.circular(12.r),
),
child: Icon(
action['icon'] as IconData,
color: action['color'] as Color,
size: 28.sp
),
),
SizedBox(height: 8.h),
Text(action['label'] as String, style: TextStyle(fontSize: 12.sp)),
],
),
);
}).toList(),
);
}
用map遍历数组生成Widget列表。每个图标的背景色是对应颜色的10%透明度,用withOpacity(0.1)实现,这样既有颜色区分又不会太刺眼。
推荐课程横向列表
推荐课程采用横向滚动的卡片列表:
Widget _buildRecommendSection(BuildContext context) {
return Column(
crossAxisAlignment: CrossAxisAlignment.start,
children: [
Row(
mainAxisAlignment: MainAxisAlignment.spaceBetween,
children: [
Text(
'推荐课程',
style: TextStyle(fontSize: 18.sp, fontWeight: FontWeight.bold)
),
TextButton(
onPressed: () => Navigator.push(
context,
MaterialPageRoute(builder: (_) => const RecommendScreen()),
),
child: const Text('查看更多'),
),
],
),
标题栏右侧有个"查看更多"按钮,点击可以跳转到完整的推荐列表页面,首页只展示部分内容。
SizedBox(height: 8.h),
SizedBox(
height: 140.h,
child: ListView.builder(
scrollDirection: Axis.horizontal,
itemCount: 5,
itemBuilder: (context, index) {
final courses = ['基础问候', '数字手语', '日常用语', '情感表达', '紧急求助'];
return Container(
width: 120.w,
margin: EdgeInsets.only(right: 12.w),
child: Card(
child: InkWell(
onTap: () {},
borderRadius: BorderRadius.circular(12.r),
child: Column(
mainAxisAlignment: MainAxisAlignment.center,
children: [
Icon(Icons.sign_language, size: 40.sp, color: const Color(0xFF00897B)),
SizedBox(height: 8.h),
Text(courses[index], style: TextStyle(fontSize: 14.sp)),
],
),
),
),
);
},
),
),
],
);
}
横向列表用ListView.builder配合scrollDirection: Axis.horizontal实现。需要给外层SizedBox一个固定高度,不然会报错。每个卡片宽度固定120,右边留12的间距。
学习分类网格
最后是学习分类模块,用GridView.builder实现3列网格:
Widget _buildCategorySection(BuildContext context) {
final categories = [
{'name': '基础入门', 'count': 20, 'icon': Icons.star},
{'name': '日常交流', 'count': 35, 'icon': Icons.chat_bubble},
{'name': '数字时间', 'count': 15, 'icon': Icons.access_time},
];
分类数据同样用数组存储,包含名称、词汇数量和图标,结构清晰明了。
return GridView.builder(
shrinkWrap: true,
physics: const NeverScrollableScrollPhysics(),
gridDelegate: SliverGridDelegateWithFixedCrossAxisCount(
crossAxisCount: 3,
crossAxisSpacing: 12.w,
mainAxisSpacing: 12.h,
childAspectRatio: 1,
),
itemCount: categories.length,
itemBuilder: (context, index) {
final category = categories[index];
return Card(
child: InkWell(
onTap: () {},
borderRadius: BorderRadius.circular(12.r),
child: Column(
mainAxisAlignment: MainAxisAlignment.center,
children: [
Icon(
category['icon'] as IconData,
size: 32.sp,
color: const Color(0xFF00897B)
),
SizedBox(height: 8.h),
Text(category['name'] as String, style: TextStyle(fontSize: 12.sp)),
Text('${category['count']}个词汇', style: TextStyle(fontSize: 10.sp, color: Colors.grey)),
],
),
),
);
},
);
}
因为GridView是放在ScrollView里面的,所以要设置shrinkWrap: true让它根据内容自适应高度。同时physics: NeverScrollableScrollPhysics()禁用GridView自身的滚动,避免滚动冲突。
小结
首页的实现主要就是把各个模块拆分成独立的方法,然后在build里组装起来。用Provider管理状态数据,用screenutil做屏幕适配,代码结构清晰,后续维护也方便。
欢迎加入开源鸿蒙跨平台社区:https://openharmonycrossplatform.csdn.net
学习日历
显示每日学习打卡情况:
Widget _buildLearningCalendar() {
return Container(
margin: EdgeInsets.all(16.w),
padding: EdgeInsets.all(16.w),
decoration: BoxDecoration(
color: Colors.white,
borderRadius: BorderRadius.circular(12.r),
boxShadow: [
BoxShadow(
color: Colors.black.withOpacity(0.05),
blurRadius: 10,
offset: const Offset(0, 2),
),
],
),
child: Column(
crossAxisAlignment: CrossAxisAlignment.start,
children: [
Row(
mainAxisAlignment: MainAxisAlignment.spaceBetween,
children: [
Text(
'学习打卡',
style: TextStyle(fontSize: 16.sp, fontWeight: FontWeight.bold),
),
Text(
'已连续打卡 7 天',
style: TextStyle(
fontSize: 12.sp,
color: const Color(0xFF00897B),
fontWeight: FontWeight.w600,
),
),
],
),
SizedBox(height: 12.h),
Row(
mainAxisAlignment: MainAxisAlignment.spaceAround,
children: List.generate(7, (index) {
final isChecked = index < 5; // 示例数据
return Column(
children: [
Text(
['一', '二', '三', '四', '五', '六', '日'][index],
style: TextStyle(fontSize: 12.sp, color: Colors.grey[600]),
),
SizedBox(height: 4.h),
Container(
width: 32.w,
height: 32.w,
decoration: BoxDecoration(
color: isChecked
? const Color(0xFF00897B)
: Colors.grey[200],
shape: BoxShape.circle,
),
child: isChecked
? Icon(Icons.check, color: Colors.white, size: 16.sp)
: null,
),
],
);
}),
),
],
),
);
}
学习日历显示一周的打卡情况,已打卡的日期显示绿色圆圈和对勾。顶部显示连续打卡天数,激励用户坚持学习。
学习目标
设置和显示学习目标:
Widget _buildLearningGoal() {
final todayMinutes = 25; // 今日学习时长
final goalMinutes = 30; // 目标时长
final progress = todayMinutes / goalMinutes;
return Container(
margin: EdgeInsets.all(16.w),
padding: EdgeInsets.all(16.w),
decoration: BoxDecoration(
gradient: const LinearGradient(
colors: [Color(0xFFFF9800), Color(0xFFFFB74D)],
begin: Alignment.topLeft,
end: Alignment.bottomRight,
),
borderRadius: BorderRadius.circular(12.r),
),
child: Column(
crossAxisAlignment: CrossAxisAlignment.start,
children: [
Row(
mainAxisAlignment: MainAxisAlignment.spaceBetween,
children: [
Text(
'今日目标',
style: TextStyle(
fontSize: 16.sp,
fontWeight: FontWeight.bold,
color: Colors.white,
),
),
Text(
'$todayMinutes / $goalMinutes 分钟',
style: TextStyle(
fontSize: 14.sp,
color: Colors.white.withOpacity(0.9),
),
),
],
),
SizedBox(height: 12.h),
ClipRRect(
borderRadius: BorderRadius.circular(10.r),
child: LinearProgressIndicator(
value: progress.clamp(0.0, 1.0),
minHeight: 8.h,
backgroundColor: Colors.white.withOpacity(0.3),
valueColor: const AlwaysStoppedAnimation<Color>(Colors.white),
),
),
SizedBox(height: 8.h),
Text(
progress >= 1.0 ? '太棒了!今日目标已完成' : '还差${goalMinutes - todayMinutes}分钟完成目标',
style: TextStyle(
fontSize: 12.sp,
color: Colors.white.withOpacity(0.9),
),
),
],
),
);
}
学习目标卡片使用橙色渐变背景,显示今日学习时长和目标时长。进度条直观展示完成情况,底部文字根据进度动态变化。
热门课程
展示热门学习内容:
Widget _buildPopularCourses() {
return Container(
margin: EdgeInsets.all(16.w),
child: Column(
crossAxisAlignment: CrossAxisAlignment.start,
children: [
Row(
mainAxisAlignment: MainAxisAlignment.spaceBetween,
children: [
Text(
'热门课程',
style: TextStyle(fontSize: 18.sp, fontWeight: FontWeight.bold),
),
TextButton(
onPressed: () {},
child: const Text('更多'),
),
],
),
SizedBox(height: 12.h),
SizedBox(
height: 180.h,
child: ListView.builder(
scrollDirection: Axis.horizontal,
itemCount: 5,
itemBuilder: (context, index) {
return Container(
width: 140.w,
margin: EdgeInsets.only(right: 12.w),
decoration: BoxDecoration(
color: Colors.white,
borderRadius: BorderRadius.circular(12.r),
boxShadow: [
BoxShadow(
color: Colors.black.withOpacity(0.05),
blurRadius: 10,
offset: const Offset(0, 2),
),
],
),
child: Column(
crossAxisAlignment: CrossAxisAlignment.start,
children: [
Container(
height: 100.h,
decoration: BoxDecoration(
color: Colors.grey[300],
borderRadius: BorderRadius.vertical(
top: Radius.circular(12.r),
),
),
child: Center(
child: Icon(
Icons.play_circle_outline,
size: 40.sp,
color: Colors.white,
),
),
),
Padding(
padding: EdgeInsets.all(8.w),
child: Column(
crossAxisAlignment: CrossAxisAlignment.start,
children: [
Text(
'课程标题 ${index + 1}',
style: TextStyle(
fontSize: 13.sp,
fontWeight: FontWeight.w600,
),
maxLines: 2,
overflow: TextOverflow.ellipsis,
),
SizedBox(height: 4.h),
Row(
children: [
Icon(Icons.people, size: 12.sp, color: Colors.grey[600]),
SizedBox(width: 4.w),
Text(
'${1000 + index * 200}人学习',
style: TextStyle(
fontSize: 11.sp,
color: Colors.grey[600],
),
),
],
),
],
),
),
],
),
);
},
),
),
],
),
);
}
热门课程使用横向滚动列表展示,每个课程卡片显示缩略图、标题和学习人数。这个功能帮助用户发现优质内容。
学习排行榜
显示学习时长排行:
Widget _buildLeaderboard() {
return Container(
margin: EdgeInsets.all(16.w),
padding: EdgeInsets.all(16.w),
decoration: BoxDecoration(
color: Colors.white,
borderRadius: BorderRadius.circular(12.r),
boxShadow: [
BoxShadow(
color: Colors.black.withOpacity(0.05),
blurRadius: 10,
offset: const Offset(0, 2),
),
],
),
child: Column(
crossAxisAlignment: CrossAxisAlignment.start,
children: [
Row(
mainAxisAlignment: MainAxisAlignment.spaceBetween,
children: [
Text(
'学习排行榜',
style: TextStyle(fontSize: 16.sp, fontWeight: FontWeight.bold),
),
Container(
padding: EdgeInsets.symmetric(horizontal: 8.w, vertical: 4.h),
decoration: BoxDecoration(
color: const Color(0xFF00897B).withOpacity(0.1),
borderRadius: BorderRadius.circular(12.r),
),
child: Text(
'我的排名: 第15名',
style: TextStyle(
fontSize: 11.sp,
color: const Color(0xFF00897B),
fontWeight: FontWeight.w600,
),
),
),
],
),
SizedBox(height: 12.h),
...List.generate(3, (index) {
final medals = ['🥇', '🥈', '🥉'];
return Container(
margin: EdgeInsets.only(bottom: 8.h),
padding: EdgeInsets.all(8.w),
decoration: BoxDecoration(
color: Colors.grey[50],
borderRadius: BorderRadius.circular(8.r),
),
child: Row(
children: [
Text(
medals[index],
style: TextStyle(fontSize: 20.sp),
),
SizedBox(width: 12.w),
CircleAvatar(
radius: 16.r,
backgroundColor: const Color(0xFF00897B).withOpacity(0.1),
child: Text(
'用户${index + 1}',
style: TextStyle(
fontSize: 10.sp,
color: const Color(0xFF00897B),
),
),
),
SizedBox(width: 8.w),
Expanded(
child: Text(
'用户${index + 1}',
style: TextStyle(fontSize: 13.sp, fontWeight: FontWeight.w500),
),
),
Text(
'${120 - index * 10}小时',
style: TextStyle(
fontSize: 12.sp,
color: const Color(0xFF00897B),
fontWeight: FontWeight.w600,
),
),
],
),
);
}),
],
),
);
}
排行榜显示学习时长前三名,使用奖牌emoji增加趣味性。顶部显示当前用户的排名,激励用户提升学习时长。
每日一句
显示每日手语短句:
Widget _buildDailyPhrase() {
return Container(
margin: EdgeInsets.all(16.w),
padding: EdgeInsets.all(16.w),
decoration: BoxDecoration(
gradient: const LinearGradient(
colors: [Color(0xFF9C27B0), Color(0xFFBA68C8)],
begin: Alignment.topLeft,
end: Alignment.bottomRight,
),
borderRadius: BorderRadius.circular(12.r),
),
child: Column(
crossAxisAlignment: CrossAxisAlignment.start,
children: [
Row(
children: [
Icon(Icons.wb_sunny, color: Colors.white, size: 24.sp),
SizedBox(width: 8.w),
Text(
'每日一句',
style: TextStyle(
fontSize: 16.sp,
fontWeight: FontWeight.bold,
color: Colors.white,
),
),
],
),
SizedBox(height: 12.h),
Text(
'你好,很高兴认识你',
style: TextStyle(
fontSize: 18.sp,
fontWeight: FontWeight.w600,
color: Colors.white,
),
),
SizedBox(height: 8.h),
Row(
children: [
TextButton.icon(
onPressed: () {},
icon: Icon(Icons.play_arrow, color: Colors.white, size: 16.sp),
label: Text(
'观看视频',
style: TextStyle(fontSize: 12.sp, color: Colors.white),
),
style: TextButton.styleFrom(
backgroundColor: Colors.white.withOpacity(0.2),
padding: EdgeInsets.symmetric(horizontal: 12.w, vertical: 6.h),
),
),
SizedBox(width: 8.w),
TextButton.icon(
onPressed: () {},
icon: Icon(Icons.bookmark_border, color: Colors.white, size: 16.sp),
label: Text(
'收藏',
style: TextStyle(fontSize: 12.sp, color: Colors.white),
),
style: TextButton.styleFrom(
backgroundColor: Colors.white.withOpacity(0.2),
padding: EdgeInsets.symmetric(horizontal: 12.w, vertical: 6.h),
),
),
],
),
],
),
);
}
每日一句卡片使用紫色渐变背景,显示一句常用手语表达。提供观看视频和收藏两个操作按钮,帮助用户学习日常用语。
总结
手语学习首页通过丰富的功能模块,为用户提供了完整的学习入口。从学习打卡到目标追踪,从热门课程到排行榜,每个功能都旨在激励用户坚持学习。每日一句功能让用户每天都能学到新知识,保持学习的新鲜感。
欢迎加入开源鸿蒙跨平台社区:https://openharmonycrossplatform.csdn.net
更多推荐
所有评论(0)
